inquiryPayment

Overview

POST /v1/payments/inquiryPayment returns the latest status of a wallet payment. Merchants poll this API when asynchronous callbacks (for example via paymentNotifyUrl) do not arrive in time. Always send requests in the smallest currency unit (IQD fils).

1. Mini Program calls my.getAuthCode with the required scopes to request authorization.
2. Wallet app service processes the authorization request and displays the consent page to the user.
3. User approves the authorization, and the wallet backend verifies the request and issues an authCode.
4. Wallet app service returns the authCode to the Mini Program.
5. Mini Program forwards the authCode to the merchant backend.
6. Merchant backend calls applyToken with the authCode to obtain tokens.
7. Wallet backend returns accessToken, refreshToken, and customerId information to the merchant backend.
8. Mini Program creates the payment order using the received customerId and sends it to the merchant backend.
9. Merchant backend invokes /v1/payments/pay to initiate the payment and receives a redirectionUrl and optional paymentNotifyUrl confirmation.
10. Merchant backend relays the redirectionUrl to the Mini Program.
11. Mini Program calls my.tradePay with the redirectionUrl to open the cashier experience.
12. Wallet app service presents the cashier UI, the user confirms the payment, and the wallet backend processes the transaction.
13. Wallet backend returns the payment result to the Mini Program and pushes notifications to the merchant backend via paymentNotifyUrl.
14. Merchant backend polls /v1/payments/inquiryPayment with paymentId or paymentRequestId, and the wallet backend responds with the latest payment status and transaction details.

Endpoint

API Structure

A message consists of a header and body. The following sections are focused on the body structure. For the header structure, see: OpenAPIs Overview.

Request

{
  "paymentRequestId": "102217200000000000001xxxx"
}

{
  "paymentId": "202312061112128001001660090000xxxx"
}

Provide either paymentId or paymentRequestId (not both). If both are provided, paymentId takes precedence.

Response

{
  "result": {
    "resultCode": "SUCCESS",
    "resultStatus": "S",
    "resultMessage": "success"
  },
  "paymentId": "202312061112128001001660090000xxxx",
  "paymentRequestId": "20230101234567890133333xxxx",
  "paymentAmount": {
    "value": "100000",
    "currency": "IQD"
  },
  "paymentTime": "2023-01-01T12:01:01+08:00",
  "paymentStatus": "SUCCESS",
  "transactions": [
    {
      "transactionAmount": {
        "value": "100000",
        "currency": "IQD"
      },
      "transactionId": "20231206111212800100xxxx",
      "transactionTime": "2023-01-01T12:01:01+08:30",
      "transactionType": "PAY",
      "transactionStatus": "SUCCESS"
    }
  ]
}

Result Processing Logic

Error Codes
